Spectrum M2i.2020-Exp Board PCI Card

Spectrum M2i.2020-Exp Board is a high-performance PCIe data acquisition (DAQ) card renowned for reliability and speed. Designed for demanding scientific and industrial measurement tasks, this PCIe capture card features a dual-channel (2 × SMA) interface with a 250 MS/s sampling rate and 8-bit accuracy. With 100 MHz bandwidth and a 256 MB onboard SDRAM cache, the M2i.2020-Exp supports high-throughput continuous streaming and real-time analysis — ideal for telecom, lab measurement, and high-speed signal processing in research environments.

Brand: Spectrum

Model: M2i.2020-Exp

Function: High-speed data acquisition / PCIe capture card

Parameters: Interface: PCIe×1; Channels: 2 × SMA; Accuracy: 8-bit; Sampling rate: 250 MS/s; Bandwidth: 100 MHz; Onboard cache: 256 MB SDRAM

Specifications: 2-channel SMA inputs/outputs, 8-bit converters, up to 250 MS/s per channel. Suitable for telecom, lab measurement, and scientific research requiring precise timing and high sample rates. Typically supplied with drivers and integration support — contact for details.
